Low Profile Self-Dumping Steel Hoppers

Availability: In stock

Units have a full 90° dump angle with a cushioned rubber bumper stop. The low profile design is essential for convenient loading. Dumping with a forklift is quick and simple. A cable is pulled from the seat of the forklift to dump the hopper. The unit returns to an upright and locked position when lowered to the ground.


A locking chain is provided to secure the hopper to the forklift.


22 "L usable fork pockets measure 7"W x 2"H on 11-5/8" centers.


Unit includes robotic welds for a consistent, durable design.


Formed base thickness is 1/4". Blue powder coat finish.

Description

Details

Units have a full 90° dump angle with a cushioned rubber bumper stop. The low profile design is essential for convenient loading. Dumping with a forklift is quick and simple. A cable is pulled from the seat of the forklift to dump the hopper. The unit returns to an upright and locked position when lowered to the ground.

A locking chain is provided to secure the hopper to the forklift.

22 "L usable fork pockets measure 7"W x 2"H on 11-5/8" centers.

Unit includes robotic welds for a consistent, durable design.

Formed base thickness is 1/4". Blue powder coat finish.

Additional Info

Additional Info

Product Type Aftermarket Parts

Related Blog Posts

Thumbnail ID Product Name Type Capacity Lbs Width Length Height Overall Size Additional Spec Weight Lbs Price Qty
Low Profile Self-Dumping Steel Hoppers Light Duty (12 ga.) - 2,000 Lb. Cap. - 25" x 46" x 18 1/4" 450 Low Profile Self-Dumping Steel Hoppers Light Duty (12 ga.) - 2,000 Lb. Cap. - 25" x 46" x 18 1/4" Light Duty 2000 lbs. 25" Depth: 46" 18 1/4" (WxDxH) 25" x 46" x 18 1/4" Fork Pocket Centers 11.625", base thickness is 1/4" 164 lbs.
$566.60
Low Profile Self-Dumping Steel Hoppers Light Duty (12 ga.) - 2,000 Lb Cap. - 25" x 51 1/4" x 28" 451 Low Profile Self-Dumping Steel Hoppers Light Duty (12 ga.) - 2,000 Lb Cap. - 25" x 51 1/4" x 28" Light Duty 2,000 lbs. 25" Depth: 51 1/4" 28" (WxDxH) 25" x 51 1/4" x 28" Fork Pocket Centers 11.625", base thickness 1/4". 205 lbs.
$645.80
Low Profile Self-Dumping Steel Hoppers  Light Duty (12 ga.) - 2,000 Lb Cap. - 49" x 51 1/4" x 28" 452 Low Profile Self-Dumping Steel Hoppers Light Duty (12 ga.) - 2,000 Lb Cap. - 49" x 51 1/4" x 28" Light Duty 2,000 lbs. 49" Depth: 51 1/4" 28" (WxDxH) 49" x 51 1/4" x 28" Fork Pocket Centers 21.625", base thickness is 1/4" 347 lbs.
$770.70
Low Profile Self-Dumping Steel Hoppers -Light Duty (12 ga.) Volume Cubic Yards 1-1/2 453 Low Profile Self-Dumping Steel Hoppers -Light Duty (12 ga.) Volume Cubic Yards 1-1/2 Light Duty 2,000 lbs. 48" Depth: 51.1/4" 41" (WxDxH) 49" x 51-1/4" x 41" Fork Pocket Centers 11.625", base thickness is 1/4" 374 lbs.
$880.40
Low Profile Self-Dumping Steel Hoppers Medium Duty (10 ga.) - 4,000 Lb Cap. - 25" x 46" x 18 454 Low Profile Self-Dumping Steel Hoppers Medium Duty (10 ga.) - 4,000 Lb Cap. - 25" x 46" x 18 Medium Duty 4,000 lbs. 25" Depth: 46" 18" (WxDxH) 25" x 46" x 18 Fork Pocket Centers 11.625", base thickness is 1/4" 164 lbs.
$592.00
Low Profile Self-Dumping Steel Hoppers Medium Duty (10 ga.)  - 4,000 Lb Cap. - 25" x 51 1/4" x 28" 455 Low Profile Self-Dumping Steel Hoppers Medium Duty (10 ga.) - 4,000 Lb Cap. - 25" x 51 1/4" x 28" Medium Duty 4,000 lbs. 25" Depth: 51 1/4" 28" (WxDxH) 25" x 51 1/4" x 28" Fork Pocket Centers 11.625", base thickness is 1/4" 258 lbs.
$676.30
Low Profile Self-Dumping Steel Hoppers Medium Duty (10 ga.)  - 4,000 Lb Cap. - 49" x 51 1/4" x 28" 456 Low Profile Self-Dumping Steel Hoppers Medium Duty (10 ga.) - 4,000 Lb Cap. - 49" x 51 1/4" x 28" Medium Duty 4,000 lbs. 49" Depth: 51 1/4" 28" (WxDxH) 49" x 51 1/4" x 28" Fork Pocket Centers 21.625", base thickness is 1/4" 362 lbs.
$790.00
Low Profile Self-Dumping Steel Hoppers Medium Duty (10 ga.) - 4,000 Lb Cap. - 49" x 51 1/4" x 41 457 Low Profile Self-Dumping Steel Hoppers Medium Duty (10 ga.) - 4,000 Lb Cap. - 49" x 51 1/4" x 41 Medium Duty 4,000 lbs. 49" 51 1/4" 41" (WxDxH) 49" x 51 1/4" x 41" Fork Pocket Centers 21.625", base thickness is 1/4" 463 lbs.
$975.80
Low Profile Self-Dumping Steel Hoppers Heavy Duty (8 ga.) - 6,000 Lb Cap. - 25" x 46" x 18 458 Low Profile Self-Dumping Steel Hoppers Heavy Duty (8 ga.) - 6,000 Lb Cap. - 25" x 46" x 18 Heavy Duty 6,000 lbs. 25" Depth: 46" 18" (WxDxH) 25" x 46" x 18 Fork Pocket Centers 11.625", base thickness is 1/4" 207 lbs.
$622.40
Low Profile Self-Dumping Steel Hoppers Heavy Duty (8 ga.) - 6,000 Lb Cap. - 25" x 51 1/4" x 28" 459 Low Profile Self-Dumping Steel Hoppers Heavy Duty (8 ga.) - 6,000 Lb Cap. - 25" x 51 1/4" x 28" Heavy Duty 6,000 lbs. 25" Depth: 51 1/4" 28" (WxDxH) 25" x 51 1/4" x 28" Fork Pocket Centers 11.625", Base thickness 1/4", 269 lbs.
$711.80
Low Profile Self-Dumping Steel Hoppers Heavy Duty (8 ga.) - 6,000 Lb Cap. - 49" x 51 1/4" x 28" 460 Low Profile Self-Dumping Steel Hoppers Heavy Duty (8 ga.) - 6,000 Lb Cap. - 49" x 51 1/4" x 28" Heavy Duty 6,000 lbs. 49" Depth: 51 1/4" 28" (WxDxH) 49" x 51 1/4" x 28" Fork Pocket Centers 21.625", base thickness 1/4" 292 lbs.
$880.40
Low Profile Self-Dumping Steel Hoppers Heavy Duty (8 ga.) - 6,000 Lb Cap. - 49" x 51 1/4" x 41" 461 Low Profile Self-Dumping Steel Hoppers Heavy Duty (8 ga.) - 6,000 Lb Cap. - 49" x 51 1/4" x 41" Heavy Duty 6,000 lbs. 49" Depth: 51 1/4" 41" (WxDxH) 49" x 51 1/4" x 41" Fork Pocket Centers 21.625", Base thickness 1/4" 467 lbs.
$1,110.80
